 ABOUT US

PENTAGON STEEL ENGINEERING is steel detailing service provider.

​

At PENTAGON STEEL ENGINEERING, we provide high quality steel detailing services and products using leading edge automated 3D technology. Our experienced team has worked on a gamut of projects, from standard to complex to oneofakind structures in commercial, industrial, public sector, recreation sectors as well as high rise and complex steel structures.

​

We approach each project with precision and attention to detail, necessary to meet customer expectations and to comply with technical requirements.

Quick Facts

  • We offer affordable, reliable & on-time detailing services with customer focused approach

  • Respond quickly and efficiently to customer’s change request and emerging issues

  • We practice proactive communication and customer involvement through our website, in-person meeting, skype or phone calls

  • We produce drawings in either metric or imperial measures

  • We follow AISC, NISD ,CISC,OSHA, EU,BIS & all Leading International Steel Detailing standards

  • We have experience in field of steel structures, globally and hands-on experience in steel detailing, with zeal for customer satisfaction

Services We Offer

  • We offer steel detailing services for structural steel and miscellaneous steel across the globe.​

​

We offer:

  • 3D modeling of complex structures (Commercial, Industrial, Special Structures & High Rise)

  • Platform Independent Steel Detailing Covering Shop & Erection (GA) drawings

  • BOMs (bills of material)/ MTO’s (Material Take Off)

  • Anchor bolt setting plans

  • Connection design (Across US + CANADA)

  • CNC, Fabsute (KISS), All Reports with DXF plates  & files for shop fabrication members material components
